Product
Focus on full solutions for the professional sugarcane planting industry
1.Equipped with a 260hp high-efficiency engine with strong power, perfectly adapting to operation in high-yield fields.
2.Fitted with crawler travelling system featuring low ground pressure, ideal for operation on soft ground.
3.Powerful climbing capacity, enabling flexible travelling on complex terrains.
4.Intelligent electro-hydraulic control system ensures simple and comfortable operation.
5.Suitable for operation on farm plots with planting row spacing ≥1.2 m.
High-performance Engine and Hydraulic System
High-level Discharge Technology
Intelligent Control System
Self-cleaning Heat Dissipation System
| Model | CHT300C | |
| Overall dimensions (mm) | 7630*2530*3910 | |
| Weight (kg) | 11300 | |
| Way of Walking | Track | |
| Structural type | Auto cut-off | |
| Travel driving mode | Hydraulic drive | |
| Power (hp/kW) | 256/191 | |
| Rated speed (r/min) | 2200 | |
| Track parameters | Track pitch (mm) | 171.45 |
| Number of tracks | 38 | |
| Track width (mm) | 400 | |
| Track gauge (mm) | 1700 | |
| Rated feed volume (kg/s) | ≥6 | |
| Traveling speed (km/h) | 0～8 | |
| Climb capacity (％) | ≥20 | |
| Feeding width (mm) | 640 | |
| Center distance of bottom cutter (mm) | 535 | |
| Width of transport channel (mm) | 600 | |
| Cane collection | Hopper | |
| Hopper bulk (㎡) | 3.2 | |
| Discharge type | End dump after lifting | |
| Harvest row | 1 | |
| Adapt to line spacing (m) | ≥1.2 | |
| Slope (％) | ≤20 | |
