Focus on full solutions for the professional sugarcane planting industry
1.Equipped with a 180 hp high-pressure common rail engine, delivering powerful performance and lower fuel consumption.
2.Adopting integrated frame beam chassis technology, the machine features a low center of gravity and stable travelling performance.
3.Patented high-position unloading technology enables easier material receiving and discharging, improving harvesting efficiency.
4.Electro-hydraulic control system with multiple selectable operation modes, supporting one-touch operation.
5.Suitable for operation on small and medium-sized farm plots with planting row spacing ≥0.9 m.
| CH300A Sugarcane Harvester Technical Parameters | |||
| NO. | Item | Unit | Parameter |
| 1 | Model | / | CH300A |
| 2 | Travel mode | / | Wheel |
| 3 | Structural type | / | Self-propelled Cut-off type |
| 4 | Transmission type | / | Hydraulic |
| 5 | Sugarcane collection (unloading) device | / | Hopper |
| 6 | Max. harvesting capacity of the sugarcane collector | kg | 1180 |
| 7 | Harvesting row | Row | Single |
| 8 | Row spacing | m | ≥1.2 |
| 9 | Engine model | / | |
| 10 | Engine rated power | kW | 133 |
| 11 | Engine rated RPM | r/min | 2200 |
| 12 | Max speed | km/h | 28 |
| 13 | Net harvesting efficiency | t/h | ≥24 |
| 14 | Impurity rate | % | ≤8 |
| 15 | Total loss rate | % | ≤7 |
| 16 | Cut cane lengh | mm | 160-230 |
| 17 | Front tire | / | |
| 18 | Front track | mm | 1670 |
| 19 | Rear tire | / | |
| 20 | Rear track | mm | 1620 |
| 21 | Wheelbase | mm | 2580 |
| 22 | Dimension(L*W*H) | mm | 7650*2450*3800 |
| 23 | Weight | kg | 8100 |
